Door Lock Non-Fatal Error E dL1 (2 of 2)
Continued from 1 of 2.
(C)
Is there 12VDC
between H7-5 and H7-6?
Yes
Is the door locked
switch closing when
the solenoid locks
the door?
Yes
Replace AP1.
No
(D)
Inspect wiring from
AP1 to SQ3 Door
Locked Switch.
Replace SQ3 if needed.
Yes
Adjust/replace
mechanical linkage.
No
Troubleshooting
©
