ALLIANCE SCL020WT - Page 28

Continued from
previous page
(M)
OPL Models: Is there
200-240VAC between
the GRY/BLK and
WHT/BLK wires on the
line and load side of
the E-Stop?
(N)
Is there 200-240VAC
between J4-3 and J4-4?
Yes
Inspect connections
and wiring to the
E-Stop. Replace
E-Stop and/or wiring
as needed.
No
(O)
Is there 200-240VAC
between H1-1 and H1-2
at AP1 I/O Board?
Yes
Inspect connections
and wiring to
connector J4. Replace
wiring if needed.
No
Verify connections
are tight at AP1.
Replace AP1 if needed.
Yes
Inspect connections
and wiring from
connector J4 to H1 on
AP1. Replace wiring
if needed.
No
Troubleshooting
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
28 Part No. F8677701EN
