Allied Telesis AT-8000S Switch
Web Browser Interface User’s Guide
• Cable Length — Indicates the approximate cable length. This test can only be performed when the port is up
and operating at 1 Gbps.
2. Select the Unit Number, and the Port.
3. Click Test. The cable test is performed.
4. Click Advanced. The Copper Cables Extended Feature Page opens, and the copper cable test results are
displayed.
Figure 94: Copper Cables Extended Feature Page

Allied Telesis AT-8000S Series Specifications

General

Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Humidity	5% to 95% non-condensing
Switching Capacity	104 Gbps
Forwarding Rate	77.4 Mpps
VLANs	4, 094
Layer 3 Features	Static routing, RIP v1/v2
Management	Web-based
Operating Humidity	10% to 90% non-condensing
