Allied Telesis AT-8000S Series User Manual

Managing Stacking
Configuring Stacking Management
Page 173
2. Select the master election method, type of ports to be used in stacking,
3. Map/assign the unit numbers.
4. Click Apply. A confirmation message displays. The stacking settings are saved and the device configuration
is updated.
5. Click Refresh. The stacking configuration is applied.
6. Click Save Config on the menu to save the changes permanently.
Note
If a different Unit ID is selected, the device must be reset for the configuration changes are active.

Allied Telesis AT-8000S Series Specifications

General

Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Humidity	5% to 95% non-condensing
Switching Capacity	104 Gbps
Forwarding Rate	77.4 Mpps
VLANs	4, 094
Layer 3 Features	Static routing, RIP v1/v2
Management	Web-based
Operating Humidity	10% to 90% non-condensing
