Allied Telesis AT-8000S Series User Manual

Configuring Ports
Configuring Port Mirroring
Page 61
To modify or delete a port mirror:
1. Click Layer 1 > Port Mirroring. The Port Mirroring Page opens.
2. Click Modify. The Modify Mirror Page opens.
3. Click the checked Enable Mirror to disable the option.
4. Modify the mirror settings on the port(s) by toggling the port until the required mirror indicator is displayed. To
delete the port mirror, toggle a port to its original (black) state.
5. Click Enable Mirror to enable the mirror again.
6. Click Apply. The destination port is modified. If indicated as black, the port is deleted from port mirrors list
and is available for normal network operations.
7. Click Save Config on the menu to permanently save the change.

Allied Telesis AT-8000S Series Specifications

General

Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Humidity	5% to 95% non-condensing
Switching Capacity	104 Gbps
Forwarding Rate	77.4 Mpps
VLANs	4, 094
Layer 3 Features	Static routing, RIP v1/v2
Management	Web-based
Operating Humidity	10% to 90% non-condensing
