Altai Technologies Ltd. All rights reserved
C1n Series WIFI AP/CPE Web-admin Configuration Manual
TPS15-003_rev1.3
Figure 5-27 Open & No Security
Configure an open WLAN without data encryption:
1. Select Configuration -> Wireless -> Radio0 -> WLAN to edit “More…” behind the
WLAN, and then select WLAN Security to access to security configuration page.
2. Select “Open” in Authentication Mode
3. Select “Disabled” in Cipher Mode
4. Click Submit
5. Click Save&Apply to apply
Figure 5-14 Open & WEP Setting
Configure an open WLAN with WEP encryption:
1. Select Configuration -> Wireless -> Radio0 -> WLAN to edit “More…” behind the
WLAN, and then select WLAN Security to access to security configuration page.
2. Select “Open” in Authentication Mode
3. Select “WEP” in Cipher Mode
4. Set the Key number (1-4) in Default WEP Key
5. Click Submit
