Managed Radio: Specify the Radio0 can managed by AC.
Creat Manage Wlan Switch: Specify whether create manage WLAN on thin AP. If
create a manage WLAN, When thin AP is disconnected to AC, User can also
manage this thin AP through manage WLAN.
WLAN Change Action: When the thin AP is disconnected to AC, It can close all WLAN
or Tunnel WLAN.
Configure the thin AP Mode:
1 Enable VLAN via Configuration ->Network ->VLAN
2 Select Configuration->Thin AP
3 Check Enable Thin AP to enable C1n thin AP mode.
4 Specify the primary AC IP address in Primary AC Address
5 Specify the Secondary AC IP address in Secondary AC Address
6 Specify the AP Name when it’s needed
7 Specify the AP Location when it’s needed
8 Select AC debug level when it’s needed
9 Specify the Managed Radio of C1n
10 Check the Create Manage Wlan Switch if necessary
11 Select Close All WLAN or Close Tunnel WLAN When the thin AP is disconnected to
AC
12 Click Submit
13 Click Save&Apply to apply
Notice: When C1n enables DHCP client, it supports DHPC Option 60 in both IPv4 and
IPv6. Administrator can specifies a DHCP Option 60 string up to 32 characters.
