AMD Vega 10 - Page 160

Signal Name Ball Reference
RSVD BC39
RSVD BC40
RSVD BD4
RSVD BD22
RSVD BD24
RSVD BD27
RSVD BD28
RSVD BD32
RSVD BD35
RSVD BD36
RSVD BD38
RSVD BD39
RSVD BD41
RSVD BD42
RSVD BE24
RSVD BE32
RSVD BE35
RSVD BE36
RSVD BE38
RSVD BE40
SCL AN10
SDA AM10
SMBCLK BC2
SMBDAT BC1
SWAPLOCKA T5
SWAPLOCKB T6
TCK AC8
TDI AB9
TDO AB8
TEMPIN AU37
TEMPINRETURN AT37
TEST6 T37
TESTEN AD8
TEST_PG AJ11
TEST_PG_BACO AV15
TMS AC7
TRST_L AA8
TS_A AL10
TX0M_DPB2N AD3
TX0M_DPD2N T3
TX0M_DPF2N G2
TX0P_DPB2P AD2
148 Pin Listings
"Vega 10" Databook
56006_1.00
