AMD Vega 10 - Page 161

Signal Name Ball Reference
TX0P_DPD2P T2
TX0P_DPF2P G1
TX1M_DPB1N AE2
TX1M_DPD1N U2
TX1M_DPF1N H3
TX1P_DPB1P AE1
TX1P_DPD1P U1
TX1P_DPF1P H2
TX2M_DPB0N AF3
TX2M_DPD0N V3
TX2M_DPF0N J2
TX2P_DPB0P AF2
TX2P_DPD0P V2
TX2P_DPF0P J1
TX3M_DPA2N AH3
TX3M_DPC2N Y3
TX3M_DPE2N M3
TX3P_DPA2P AH2
TX3P_DPC2P Y2
TX3P_DPE2P M2
TX4M_DPA1N AJ2
TX4M_DPC1N AA2
TX4M_DPE1N N2
TX4P_DPA1P AJ1
TX4P_DPC1P AA1
TX4P_DPE1P N1
TX5M_DPA0N AK3
TX5M_DPC0N AB3
TX5M_DPE0N P3
TX5P_DPA0P AK2
TX5P_DPC0P AB2
TX5P_DPE0P P2
TXCAM_DPA3N AG2
TXCAP_DPA3P AG1
TXCBM_DPB3N AC2
TXCBP_DPB3P AC1
TXCCM_DPC3N W2
TXCCP_DPC3P W1
TXCDM_DPD3N R2
TXCDP_DPD3P R1
TXCEM_DPE3N L2
TXCEP_DPE3P L1
Pin Listings 149
© 2017 Advanced Micro Devices, Inc.
AMD Confidential - Do not duplicate.
"Vega 10" Databook
56006_1.00
