Controller / User Interface | 4-63
Host Runtime
The length of time the Host Controller board has been operational
since the last analyzer reset.
Micro Runtime
The length of time the Microcontroller board has been operational
since the last analyzer reset.
Host Controller Board software version
Displayed next to Host Runtime (HC/93x Vx.xx), only if the Con-
figurator Software is communicating with the analyzer.
Microcontroller Board software version
Displayed next to Micro Runtime (MC93x Vx.xx), only if the Con-
figurator Software is communicating with the analyzer.
SN#
Analyzer’s serial number, displayed only if the Configurator Soft-
ware is communicating with the analyzer.
HC Scode
Displays active alarm conditions that originate from the Host Con-
troller board. Each alarm is preceded by its status number, followed
by the type of alarm (Fault or Warning), and the alarm description.
The sum of their respective primary codes is listed in the ‘f’ault and
‘w’arning fields next to HC Scode.
For a complete list of alarms generated by the Host Controller board,
refer to Chapter 6.
MC Scode
Displays active alarm conditions that originate from the Microcon-
troller board. Each alarm is preceded by its status number, followed
by the type of alarm (Fault or Warning), and the alarm description.
The sum of their respective primary codes is listed in the ‘f’ault and
‘w’arning fields next to MC Scode.
For a complete list of alarms generated by the Microcontroller board,
refer to Chapter 6.
NOTE
NOTE
