7-6 | Model 933S UV Analyzer
Filterblock Spare Parts
Qty Qty
Part No. Description (1 Year) (2 Year)
100-2607 Kit, Filterblock Rebuild (See Note 3a) 1 2
100-2598 Flow Restrictor (See Note 3b)
c/w O-ring, Aas, #008 (Part No. 300-6241) 4 8
300-6244 O-ring, Aas, #006 2 4
300-5862 High-Flow Membrane Filter (c/w o-ring) 1 2
300-8594 Type-5 Membrane Filter (c/w o-ring) 1 2
300-6257 Sintered Disk, 20 Micron Pore Size 4 8
300-6242 O-ring, Aas, #115 1 2
300-6217 Filter Cartridge (Element Coalescing) 1 2
300-2375 O-ring, Viton, #010 1 2
Note 3a: * This kit contains exact quantities of replaceable parts for a complete rebuild. For additional quantities of
individual spare parts, order using the individual spare part number below the Kit description.
Note 3b: In natural gas streams that are extremely dirty, the Flow Restrictor in the first filter stage (and possibly the
second filter stage) may need to be changed more often because it removes most of the liquids and particulate
from the gas.
The Filterblock Spare Parts list contains a complete Filterblock Re-
build Kit and individual spare parts for the Natural Gas Filterblock
Assembly. Order the Kit or individual spare parts as required.
Spare Analyzer Fuses
AMETEK recommends having on-site spare fuses used in the analyzer.
These fuses do not need to be changed out at regular intervals, but are
necessary in the event that a fuse has blown and a replacement is re-
quired.
Analyzer Fuses, 120 VAC/240 VAC
120 V 240 V
Description (Location‡) Part No. Fuse Type Part No. Fuse Type
Upper Enclosure (F4) 300-9839 2.0 A 300-9244 1.0 A
Column Heater (F3) 300-9839 2.0 A 300-9244 1.0 A
DC Power Supply (F2) 300-9244 1.0 A 300-9244 1.0 A
Main Power (F1) 300-9838 4.0 A 300-9839 2.0 A
These fuses are located on the AC Distribution board in the Lower Enclosure. See Lower Enclosure Layout drawing
(WX-14838) in Appendix A and the AC Distribution board drawing (P/N 100-1771) in “Troubleshooting and Diagnostics”
in Chapter 6.
NOTE
