Service and Parts | 7-5
Measuring Cell Spare Parts
Qty Qty
Part No. Description (1 Year) (2 Year)
Standard Measuring Cells
(5 cm, 10 cm, 15 cm, 20 cm, 40 cm, etc.)
300-0281 Cell Window, Fused Silica 2 4
100-2009 O-Ring, Size 125, Baked Aas (See Note) 6 12
Low Range (White) Cell (100-1780)
(81.2 cm)
300-0281 Cell Window, Fused Silica 1 2
300-6288 Window/Mirror Combination 1 2
300-9060 O-Ring, HSN, #125 (See Note) 8 16
Cell O-ring materials (and part numbers) may vary, depending on
the application. Before ordering spare parts, refer to the “Supplemen-
tal Information” folder of the analyzer Documentation Package
CD for a non-standard Measuring Cell Manual Supplement or a
Custom Spare Parts list. If either document is included, order spare
parts listed in that document; if not, use the part numbers (above) for
the Measuring Cell used by your analyzer.
Column Block Spare Parts, 120 VAC/240 VAC Analyzer
Qty Qty
Part No. Description (1 Year) (2 Year)
100-1788 Check Valve 0 2
(Column Block)
100-2416 Flow Restrictor, Set of 2 (See Note 1A)
c/w O-ring, Aas, #008 (Part No. 300-6241) 0 2
(Column Block)
300-9060 O-ring, HSN, #125 2 4
(Column Block)
300-2375 O-ring, Viton, 2-010 0 4
(Filter Spool, Column Block)
300-6217 Coalescing Filter Element 0 2
(Filter Spool, Column Block)
300-9147 O-ring, Aas, #113 0 4
(Filter Spool, Column Block)
300-8719 O-ring, Aas, #121 (See Note 1B) 0 4
(Column, Column Block)
Note 1A: Replace the Flow Restrictors if system flow rates have decreased to unacceptable levels.
Note 1B: These o-rings are required only if the Column Assemblies are not damaged and can be reused. New Columns
come with o-rings.
Note 2: To order new Column Assemblies, contact AMETEK.

