AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 27 / 80
Test routines
Quick Start
Immediate start, all parameters adjustable during a running test
Standard test as per
IEC 61000-4-18 level 1 up to level 3
IEC 61000-4-18 Manual operated standard test routine
User test routines
Synchronized
Random release
Voltage change after T by steps of dV
Change polarity after T
Option required for Magnetic Field Test per IEC 61000-4-10
- Magnetic field antenna MS 100 (square 1m x 1m coil)
- Adapter cable for connecting the square coil to the OCS output (twisted pair of cable max. 3 m, part of the antenna
delivery).
