AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 35 / 80
6.1.2.2.
Manual testing
The manual test menu is only in the single phase equipment available.
Manual standard test routine
Damped Osc. 1MHz IEC 61000-4-18
<- -> O
Level 3 + 2000V L PE 400/s
Testtime 0:00:45 h
START + /- L-PE N-PE L+N-PE /
Common mode menu
F1
F2
F3
F4
F5
F6
F7
START + /- L-N /
Differential mode menu
F1
F2
F3
F4
F5
F6
F7
Within this test routine all standard parameters can be changed online during testing. This procedure therefore is
very easy and fast to use.
Example:
- By pushing the cursor ➔ the test level will be increased/decreased to the next standard level.
- By turning the INC knob (o) the test level can be continuously adjusted.
- Pressing the function keys the related function will be immediately activated.
- The displayed time will be resettled to zero after every new setting.
All functions can be operated during the running test.
