Ampac EvacU Elite - Multi-Purpose Interface Card; Distribution CPU Card

Page 117
EVACU ELITE INSTALLATION, COMMISSIONING AND USER MANUAL
10.7 Multi-purpose interface card
Parameter
Detail
No. of Inputs
8
No. of Outputs
2
Serial port
Not configurable
FDCIE interface
Suitable only for Ampac FireFinder
PLUS
, RJ45 connector, CAT5/6 wiring,
max length 3m
Isolated differential input with
fault feedback
1 available, with 10KΩ EOL supervision, floating reference (30VDC max)
with user selectable resistive fault feedback
Isolated differential inputs
3 available, with 10KΩ EOL monitoring, individual floating reference
(30VDC max)
Isolated single ended inputs
4 available, with 10KΩ EOL monitoring, common floating reference (30VDC
max)
Relay outputs (VFC)
2 available, max voltage 48VDC/30VAC, max current 1amp @ 30VDC,
0.5amp @ 30VAC
No. of rack slots required
1
Max input voltage (for 8 x
inputs)
30VDC
Max cable size (inputs,
relays)
1.5mm
2
Current consumption
0.039 amps (quiescent)
10.8 Distribution CPU card
Parameter
Detail
Relay 1
Double pole, single throw (2 x COM, 1xNo, 1xNC)
Relay 2 and 3
Single pole, double throw (COM, NO, NC)
Relay Rating
Max voltage 48VDC / 30 VAC max current 1 amp @ 30VDC, 0.5amp @
30VAC
Ethernet
RJ45 – Primary GUI with proprietary power and transformer isolation
Ethernet
RJ45 – Remote paging consoles with proprietary power and transformer
isolation
BGM
2 channels, 10kΩ impedance, max input +4 dBu, cable length max of 3m
Inputs
2 – single ended, common floating reference (max 30VDC), selectable EOL
(none, 3K3, 4K7, 10K)
Max input voltage (for 2 x
inputs)
30VDC
Max cable size (inputs, BGM,
relays)
1.5mm
2
Micro SD
1 available
Mini USB
Device connection
Digital Audio
MLVDS, 2 x lanes of TDM bidirectional, data rate 8.192 Mbps per lane.
Supports 64 audio streams at 16kHz @ 16bits / 32 audio streams at 32kHz
@ 16 bits
Control signal inputs
CAN, MLVDS @ 12Mbps
No. of rack slots
1
Current consumption
0.085 amps (quiescent)
