Page 78
EVACU ELITE INSTALLATION, COMMISSIONING AND USER MANUAL
The number of power supply modules fitted determines the rating of the battery isolator and the battery cabling
size. The actual battery cable required does depend on the type of lugs on the batteries.
No. of power supplies fitted
Rating of battery isolator
Battery cable
1 60 amps
CAB3074 – M6 lugs 16mm
2
cable
CAB3075 – M10 lugs 16mm
2
cable
2
120 amps
CAB3076 – M10 lugs 25mm
2
cable
3
175 amps
CAB3077 – M10 lugs 35mm
2
cable
7.8 Recommended Batteries
The maximum capacity battery that can be fitted to the 13U cabinet is 12V 100 AmpHr.
The maximum capacity battery that can be fitted to the 24U cabinet is 12V 190 AmpHr.
Certified 12VDC sealed lead acid batteries shall be used in the 13U and 24U EvacU
ELITE
cabinets.
As per IEC 62368, certified batteries shall comply with the following relevant standards: IEC 60086-4, IEC
60086-5, IEC 60896-11, IEC 60896-21, IEC 60896-22, IEC 61056-1 and IEC 61056-2, IEC 61427, IEC/TS
61430, IEC 61434, IEC 61959, IEC 62133, IEC 62281, and IEC 62485-2.
