Chapter 5 — Assembly Replacement 5-3 Opening the Spectrum Master Case

MS2720T MM PN: 10580-00342 Rev. D 5-5

Figure 5-4. SPA Analyzer PCB Assembly (Top) and Main PCB Assembly (Bottom)

Fan and Fan

Connector

Battery

Connector

Encoder PCB

and Connector

Main PCB

(Under shielding)

Spectrum Analyzer Assembly

(Specify Spectrum Master model)

Option 31 PCB

Top Connector Panel

(Replaced with the SPA Assembly)

Bend Tab Over Option 31 Cable

and Encoder Wires
