Anritsu Spectrum Master MS2720T Maintenance Manual

Chapter 5 — Assembly Replacement 5-6 Main PCB Assembly Replacement
MS2720T MM PN: 10580-00342 Rev. D 5-9
7. Remove the 7 Torx (T10) screws retaining the Main PCB Assembly to the Spectrum Master case
(Figure 5-8).
8. Pull the Main PCB assembly out of the Front Panel section.
9. Replacement is the reverse of removal.
Figure 5-8. Remove the 7 Screws Retaining the Main PCB Assembly
Remove the 7 screws
