Appendix A — Test Records A-2 Test Records for Spectrum Analyzer Verification
MS2720T MM PN: 10580-00342 Rev. D A-3
Input Related Spurs for –30 dBm Input at 1000 MHz
Input Related Spurs for –30 dBm Input at 3273 MHz
Input Related Spurs for –30 dBm Input at 8000 MHz
Input Related Spurs for –30 dBm Input at 15000 MHz
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-4. Measured Input Signal Level at 1000 MHz
Start Freq Stop Freq Measured Spur Level Calculated IRS Specification
1000 MHz Center
Frequency
dBm
719MHz 721MHz dBm dBc ≤ –60 dBc
Table A-5. Measured Input Signal Level at 3273 MHz
Start Freq Stop Freq Measured Spur Level Calculated IRS Specification
3275 MHz Center
Frequency
dBm
2423 MHz 3271 MHz dBm dBc ≤ –60 dBc
3275 MHz 4123 MHz dBm dBc ≤ –60 dBc
Table A-6. Measured Input Signal Level at 8000 MHz
Start Freq Stop Freq Measured Spur Level Calculated IRS Specification
8000 MHz Center
Frequency
dBm
7719 MHz 7721 MHz dBm dBc ≤ –60 dBc
Table A-7. Measured Input Signal Level at 15000 MHz
Start Freq Stop Freq Measured Spur Level Calculated IRS Specification
15000 MHz Center
Frequency
dBm
14719 MHz 14721 MHz dBm dBc ≤ –60 dBc
To Next Page
