A-2 Test Records for Spectrum Analyzer Verification Appendix A — Test Records
A-4 PN: 10580-00342 Rev. D MS2720T MM
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-8. Spectrum Analyzer Resolution Bandwidth Accuracy
RBW Setting Span VBW Measured Value Specification
10 MHz 20 MHz 1 MHz MHz 9 MHz to 11 MHz
3MHz 6MHz 300kHz MHz 2.7MHz to 3.3MHz
1MHz 2MHz 100kHz MHz 900kHz to 1.1MHz
300kHz 600kHz 30kHz kHz 270kHz to 330kHz
100kHz 200kHz 10kHz kHz 90kHz to 110kHz
30 kHz 60 kHz 3 kHz kHz 27 kHz to 33 kHz
10 kHz 20 kHz 1 kHz kHz 9 kHz to 11 kHz
3kHz 6kHz 300Hz kHz 2.7kHz to 3.3kHz
1kHz 2kHz 100Hz Hz 900Hz to 1.1kHz
300 Hz 600 Hz 30 Hz Hz 270 Hz to 330 Hz
100 Hz 200 Hz 10 Hz Hz 90 Hz to 110 Hz
30 Hz 60 Hz 3 Hz Hz 27 Hz to 33 Hz
10 Hz 20 Hz 1 Hz Hz 9 Hz to 11 Hz
3Hz 10Hz 1Hz Hz 2.7Hz to 3.3Hz
1Hz 10Hz 1Hz Hz 0.9Hz to 1.1Hz
