A-2 Test Records for Spectrum Analyzer Verification Appendix A — Test Records

A-30 PN: 10580-00342 Rev. D MS2720T MM

MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________

Serial Number: _______________ Options: __________________________________________________

Note

The listed Amplitude Accuracy specifications apply when the instrument is being verified in an

environment between 20°C and 30°C after a 30 minute warm-up period. For an instrument that is not

being verified in a temperature controlled environment, but within a temperature range between

–10°C and 55°C and after a 60 minute warm-up, add ± 1 dB to the Amplitude Accuracy specification

for frequencies from 100 kHz to 40 GHz.

Table A-56. Verification at 39499.1 MHz, Specification = ± 2.3 dB

Input Power Atten Lvl Marker 1 Reading

–30dBm 0dB dBm

–30dBm 5dB dBm

–30 dBm 10 dB dBm

–30 dBm 20 dB dBm

–5 dBm 30 dB dBm

–5 dBm 40 dB dBm

–5 dBm 50 dB dBm

–5 dBm 60 dB dBm

Table A-57. Verification at 39999.1 GHz, Specification = ± 2.3 dB
