Appendix A — Test Records A-2 Test Records for Spectrum Analyzer Verification
MS2720T MM PN: 10580-00342 Rev. D A-31
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-58. Spectrum Analyzer Residual Spurious (Preamp Off)
Start Freq Stop Freq RBW VBW
Measured Values
(Marker 1) Specification
9kHz 100kHz 300Hz 10Hz dBm ≤ –90 dBm
100 kHz 30 MHz 1 kHz 100 Hz dBm ≤ –90 dBm
30 MHz 5.35 GHz 3 kHz 300 Hz dBm ≤ –90 dBm
5.35 GHz 9 GHz 3 kHz 100 Hz dBm ≤ –90 dBm
9GHz 11.11GHz 1kHz 100Hz dBm ≤ –90 dBm
11.11 GHz 13 GHz 3 kHz 300 Hz dBm ≤ –90 dBm
13 GHz 16.5 GHz 1 kHz 300 Hz dBm ≤ –85 dBm
16.5 GHz 20 GHz 1 kHz 100 Hz dBm ≤ –85 dBm
20 GHz 26 GHz 3 kHz 300 Hz dBm ≤ –80 dBm
26 GHz 32 GHz 3 kHz 300 Hz dBm
≤ –80 dBm
32 GHz 43 GHz 3 kHz 300 Hz dBm
≤ –80 dBm
Table A-59. Spectrum Analyzer Residual Spurious (Preamp On)
Start Freq Stop Freq RBW VBW Measured Values (Marker 1) Specification
1 MHz 30 MHz 3 kHz 300 Hz dBm ≤ –100 dBm
30 MHz 9 GHz 3 kHz 300 Hz dBm ≤ –100 dBm
9GHz 13GHz 10kHz 1kHz dBm ≤ –100 dBm
13 GHz 16.5 GHz 10 kHz 1 kHz dBm ≤ –100 dBm
16.5 GHz 20 GHz 1 kHz 100 Hz dBm ≤ –100 dBm
20GHz 28GHz 3kHz 300Hz dBm ≤ –100 dBm
28 GHz 32 GHz 3 kHz 300 Hz dBm ≤ –100 dBm
32 GHz 43 GHz 3 kHz 300 Hz dBm ≤ –95 dBm
