SBC-GX1 Technical Manual Appendix G – Display Converter 1 (DC1)
Appendix G – Display Converter 1 (DC1)
The Display Converter 1 (DC1) can be used with the SBC-GX1 to support Dual Scan
STN (DSTN) and Single Scan STN (SSTN) displays.
The DC1 has been designed to support two specific displays:
• Sharp LM8V302 16-bit color DSTN display.
• Nan Ya LTBLDT168G16C 8-bit monochrome DSTN display.
Other displays may be used with the correct adjustments to the connections and
configuration.
There are two variants of the DC1 available:
Variant Description
DC1-Color DC1 configured for Sharpo LM8V302 DSTN display.
DC1-Mono DC1 configured for Nan Ya DSTN display.
The connector pinouts have been designed to provide simple connection to these
displays.
