Page #25 background image
SBC-GX1 Technical Manual Award BIOS setup
Award BIOS setup
The SBC-GX1 is normally supplied with an Award Software BIOS. This section explains
how to use the CMOS Setup Utility to modify the Award BIOS configuration.
In order to support Windows CE. NET and Windows XP Embedded, the SBC-
GX1 requires a General Software Embedded BIOS 2000. If your board is using
the General Software BIOS, see page 42
for setup information.
To launch the CMOS Setup Utility:
1 Turn on the computer. The Power On Self Test (POST) routine then starts. A short
while into this routine the following message is displayed:
Press DEL to enter SETUP
2 Press either the Del key or the Ctrl, Alt, and Esc keys simultaneously.
If the message disappears before you respond and you still wish to enter setup,
restart the computer to try again by pressing the ‘reset’ button, turning it off and
back on, or pressing the Ctrl, Alt, and Del keys simultaneously.
© 2004 Arcom Issue D 25
