SBC-GX1 Technical Manual Award BIOS setup
Integrated peripherals
ROM PC/ISA BIOS (2A434001)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
IDE HDD Block Mode : Enabled ECP mode User DMA : 3
Primary IDE Channel : Enabled Build in CPU Audio : Enabled
Master Drive PIO Mode : Auto Audio I/O Base Address : 220H
Slave Drive PIO Mode : Auto MPU-401 I/O Base Address: 330H
Master UDMA : Auto Audio IRQ Select : IRQ5
Slave UDMA : Auto Audio Low DMA Select : DMA 1
Secondary IDE Channel : Enabled Audio High DMA Select : DMA 5
Master Drive PIO Mode : Auto
Master Drive UDMA : Auto Multiple Monitor Support: No On-board
Video Memory Size : 2.5M
KBC input clock : 12 MHz Display Status : Both
On-board FDC Controller: Enabled Flat Panel Type : 640x480
On-board Serial port 1 : 3F8/IRQ4
On-board Serial port 2 : 2F8/IRQ3
On-board Parallel Port : 378/IRQ7
Parallel Port Mode : ECP & EPP Esc: Quit ÇÈÆÅ: Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Colour
F6 : Load BIOS Default
F7 : Load Setup Default
Field Description
IDE HDD Block Mode
Enables/Disables block mode IDE transfers.
Primary IDE Channel
Enables/Disables the Primary IDE controller.
Master Drive PIO Mode
Enables/Disables Programmable I/O mode for the
Primary Master.
Slave Drive PIO Mode
Enables/Disables Programmable I/O mode for the
Primary Slave.
Master UDMA
Enables/Disables Ultra DMA operation for the Primary
Master.
Slave UDMA
Enables/Disables Ultra DMA operation for the Primary
Slave.
Secondary IDE Channel
Enables/Disables the Secondary IDE controller.
Master Drive PIO Mode
Enables/Disables Programmable I/O mode for the
Secondary Master.
continued…
