SBC-GX1 Technical Manual Appendix E – TFT display interface cable
Appendix E – TFT display interface cable
The following table shows the connection details for the NEC 6.5” LCD flat panel display
NL6448BC20-08E used in the development kits:
SBC-GX1 PL15 DF9M-31 D-Type Panel Signal Name
26 28 +5V Power
27 29 +5V Power
32 27 DE
29 4 VSYNC
28 3 HSYNC
24 2 SHCLK
2 21 P3
1 20 P2
4 23 P5
3 22 P4
7 25 P7
6 24 P6
8 13 P10
9 14 P11
12 16 P13
11 15 P12
14 18 P15
13 17 P14
17 7 P19
16 6 P18
19 9 P21
18 8 P20
22 11 P23
21 10 P22
5,10,15,20,23,25 1,5,12,19,26 GND
The following table shows the connection details for the backlight inverter cable:
SBC-GX1 PL15 DF13-6S Housing
30 1,2
31 3,4
Pins 5 and 6 of the 6 way housing are not used and should be removed.
© 2004 Arcom Issue D 97
