SBC-GX1 Technical Manual Appendix B – Connector details
PL3 – Ethernet Status LEDs
Connector: 4-way, 2.54mm (0.1”) single row header.
Mating Connector:
Framatome 65240-004
Pin Signal Name
1 +5V
2 100Mbps
3 10Mbps
4 LINK
1
4
PL4 - PCI connector
Connector: 120-way PCI Card edge connector (5V 32-bit 33MHz PCI socket)
Pin Side B Side A Pin Side B Side A
1 -12V /TRST 32 AD17 AD16
2 TCK +12V 33 /CBE2 +3.3V
3 GND TMS 34 GND /FRAME
4 TDO TDI 35 /IRDY GND
5 +5V +5V 36 +3.3V /TRDY
6 +5V /INTC 37 /DEVSEL GND
7 /INTD /INTA 38 GND /STOP
8 /INTB +5V 39 /LOCK +3.3V
9 /PRSNT1 RSVD 40 /PERR SDONE
10 RSVD +5V(I/O) 41 +3.3V /SBO
11 /PRSNT2 RSVD 42 /SERR GND
12 KEY KEY 43 +3.3V PAR
13 KEY KEY 44 /CBE1 AD15
14 RSVD RSVD 45 AD14 +3.3V
15 GND /RST 46 GND AD13
16 CLK +5V(I/O) 47 AD12 AD11
17 GND /GNT 48 AD10 GND
18 /REG GND 49 M66EN AD09
19 +5V(I/O) RSVD 50 GND GND
20 AD31 AD30 51 GND GND
21 AD29 +3.3V 52 AD08 /CBE0
22 GND AD28 53 AD07 +3.3V
23 AD27 AD26 54 +3.3V AD06
24 AD25 GND 55 AD05 AD04
25 +3.3V AD24 56 AD03 GND
26 /CBE3 IDSEL 57 GND AD02
27 AD23 +3.3V 58 AD01 AD00
28 GND AD22 59 +5V(I/O) +5V(I/O)
29 AD21 AD20 60 /ACK64 /REQ64
30 AD19 GND 61 +5V +5V
31 +3.3V AD18 62 +5V +5V
A62
B62
A1
B1
© 2004 Arcom Issue D 84
