SBC-GX1 Technical Manual Appendix B – Connector details
PL22 – In-system-programming header
This connector is used at assembly time only
PL24 - 16-bit SoundBlaster
Connector: 10-way, 2.54mm (0.1”) x 2.54mm (0.1”) dual row pin header
Mating Connector:
Framatome 71600-010
Pin Signal Name
1 Audio ground reference
2 Microphone IN
3 Audio ground reference
4 Line input LEFT
5 Audio ground reference
6 Line input RIGHT
7 Audio ground reference
8 Line output LEFT
9 Audio ground reference
10 Line output RIGHT
10
91
2
PL25 - CompactFlash connector
Connector: 50 pin CompactFlash right angle with latches.
Pin Signal Name Pin Signal Name
1 Ground 2 D03
3 D04 4 D05
5 D06 6 D07
7 /CS0 8 A10
9 /ATA SEL 10 A09
11 A08 12 A07
13 +5V 14 A06
15 A05 16 A04
17 A03 18 A02
continued…
© 2004 Arcom Issue D 93
