Table 5-7 Expansion connector EXP2, J8, signal list (continued)
Pin Signal Pin Signal
7 EXP29 8 EXP43
9 EXP30 Clock output 10 EXP44 Clock output
11 GND 12 GND
13 EXP31 Clock output 14 EXP45
15 EXP32 16 EXP46
17 EXP33 18 EXP47
19 EXP34 20 EXP48
21 EXP35 22 EXP49 Clock input
23 EXP36 24 GND
25 EXP37 26 3V
27 3V 28 GND
29 GND 30 3V
31 EXP38 32 EXP50 Clock output
33 EXP39 34 EXP51
Note
Pins 9, 10, 13, 22 and 32 of connector EXP2 have source series termination resistors. These resistors
help to maintain the integrity of high-slew rate signals:
Arm recommends pins 9, 10, 13 and 32 for use as clock outputs or sensitive data outputs in
preference to other pins.
Arm recommends pin 22 of connector EXP2 for use as a clock input in preference to other pins.
Related information
2.4 User expansion port on page 2-28
1.3 Location of components on the MPS2 FPGA Prototyping Board on page 1-17
1.4 Location of components on the MPS2+ FPGA Prototyping Board on page 1-19
5 Signal Descriptions
5.2 Expansion connectors
100112_0200_09_en Copyright © 2013–2016, 2018–2020 Arm Limited or its affiliates. All
rights reserved.
5-81
Non-Confidential
