5.10 12V power connector
The MPS2 and MPS2+ FPGA Prototyping Boards each provide a Thru-hole DC power jack for
connecting external power to the board.
Connect the external mains power supply unit, which Arm supplies, to the power jack.
Alternatively, you can connect an external 12V, +/- 10%, power supply to the power jack to supply
power to the board.
Note
The center pin is the positive side of the power supply.
Related information
2.14 Power on page 2-42
1.3 Location of components on the MPS2 FPGA Prototyping Board on page 1-17
1.4 Location of components on the MPS2+ FPGA Prototyping Board on page 1-19
5 Signal Descriptions
5.10 12V power connector
