42 | Instant User Interface Aruba Instant 6.5.0.0-4.3.0.0 | User Guide
Name Description
Info section in the Virtual
Controller view
The Info section in the Virtual Controller view displays the following information:
l Name—Displays the VC name.
l Country Code—Displays the Country in which the VC is operating.
l Virtual Controller IP address—Displays the IP address of the VC.
l VC DNS—Displays the DNS IP address configured for the VC.
l Management—Indicates if the IAP is managed locally or through AirWave or
Aruba Central.
l Master—Displays the IP address of the IAP acting as VC.
l OpenDNS Status—Displays the OpenDNS status. If the OpenDNS status
indicates Not Connected, ensure that the network connection is up and
appropriate credentials are configured for OpenDNS.
l MAS integration—Displays the status of the Mobility Access Switch (MAS)
integration feature.
l Uplink type—Displays the type of uplink configured on the IAP, for example,
Ethernet or 3G.
l Uplink status—Indicates the uplink status.
l Blacklisted clients—Displays the number of blacklisted clients.
l Internal RADIUS Users—Displays the number of internal RADIUSusers.
l Internal Guest Users—Displays the number of internal guest users.
l Internal User Open Slots—Displays the available slots for user configuration
as supported by the IAP model.
Info section in the Network
view
The Info section in the Network view displays the following information:
l Name—Displays the name of the network.
l Status—Displays the status of the network.
l Type—Displays the type of network, for example, Employee, Guest, or Voice.
l VLAN—Displays VLAN details.
l IP Assignment—Indicates if the IAP clients are assigned IP address from the
network that the VC is connected to, or from an internal autogenerated IP
scope from the VC.
l Access—Indicates the level of access control configured for the network.
l WMM DSCP—Displays Wi-Fi Multemedia (WMM)DSCP mapping details.
l Security level—Indicates the type of user authentication and data encryption
configured for the network.
The info section for WLAN SSIDs also indicates status of captive portal and CALEA
ACLs and provides a link to upload certificates for the internal server. For more
information, see Uploading Certificates on page 179.
Info section in the Access
Point view
The Info section in the Access Point view displays the following information:
l Name—Displays the name of the selected IAP.
l IP Address—Displays the IP address of the IAP.
Table 10: Contents of the Info Section in the Instant Main Window
