A - 4
Appendices
Figure A-5 8300 - End view showing air intake louvres and maintenance access doors.
A - 5
Appendices
8400 - Installation Diagrams
Figure A-6 8400 - Front View showing control room access and external supply inlet.
Figure A-7 8400 - Rear view showing Supply-on-Test entry and fork lift pockets
Maintenance access doors
Fork Lift Pocket
Centres (2050)
Cable entry sock
Cable termination access panel
6058
Hot air exhaust
Hot air exhaust
