ATI Technologies Axia80-M20 User Manual

Manual, F/T Sensor, Ethernet Axia
Document #9610-05-Ethernet Axia-09
Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel:+1 919.772.0115 • Fax:+1 919.772.8259 • www.ati-ia.com
68
Table 8.3—“CAL” | “SET” Fields and Values
Field Long Name Description Example Contents Type
User
Read/
Write
adcRate N/A
The ADC update
rate in Hz. The
ADC rate must
be one of the
following in units
of Hz:
488
976
1953
3906
7812
(refer toTable 4.5)
976
16-bit
integer
Read
and
Write
rdtRate
N/A
The RDT
transmission rate
in units of Hz. The
RDT transmission
rate must be 1 to
the adcRate.
40
16-bit
integer
Read
and
Write
rdtSize
The number of
RDT records to
include in each
UDP packet that is
transmitted.
lTc N/A
TheIIRltershift
value (refer to
Table 4.6)
0
8-bit integer
Read
and
Write
calib N/A
The calibration to
use:
0 or 1
This bit controls
which of the two
sets of calibrations
are displayed in
the preceding
elds.
(refer to Table
15.3)
0
8-bit integer
Read
and
Write
location N/A
Display the
physical location
of the sensor.
Alex’s Bench
String(40)
Read
and
Write
serNum
N/A
The serial number
Serial number
String(100)
Read
hwProdCode
The hardware
product code
HW Product Code
String(20)
hwRev
The hardware
revision number
0
16-bit
integer
