5. Other symbols
Symbol Title and indication
Setting
Indicates that a setting is increased.
Setting
Indicates that a setting is decreased.
AC Power
Indicates that the AC power is being supplied if an adjacent indicator is on.
Indicates that the AC power is not being supplied if an adjacent indicator is off.
Alarm
Indicates that an audible alarm is silenced.
Alarm
Indicates that a system of the unit is in an abnormal condition.
Alarm
Indicates that the rotation of the fan is abnormal or the fan has not been attached.
Alarm
Indicates an alarm related to temperature.
Alarm
Indicates an alarm related to a skin temperature probe.
Battery
Indicates the power level of battery 1 and 2.
24V12V
DC power connecting port
Indicates the DC power connecting port of the main body.
Alarm
Indicates excessive temperature condition.
Alarm
Indicates a low battery level.
Alarm
Indicates an alarm related to the SpO
2
patient cable. (For Masimo pulse oximeter)
Alarm
Indicates an alarm related to a failure of the SpO
2
patient cable. (For Masimo pulse oximeter)
Alarm
Indicates an alarm related to the SpO
2
sensor.
Alarm
Indicates an alarm related to a failure of the SpO
2
sensor.
Alarm
Indicates an alarm related to a failure of the SpO
2
sensor function.
