AudioCodes 420HD - Setting up the Phone; Unpacking; Device Description; Front View

User's Manual 2. Setting up the Phone
Version 2.0.13 11 420HD IP Phone for Microsoft Skype for Business
2 Setting up the Phone
2.1 Unpacking
When unpacking, ensure that the following items are present and undamaged:
420HD IP Phone / Stand Handset / Cord
Cat 5e Ethernet Cable AC Power Adapter (Optional)
If anything appears to be missing or broken, contact the distributor from whom you purchased the
phone for assistance.
2.2 Device Description
Use the graphics below to identify and familiarize yourself with the device's hardware functions.
2.2.1 Front View
The front view of the phone is shown in Figure 2-1 and described in Table 2-1.
