AudioCodes 420HD - Verifying IP Phone Pairing

420HD IP Phone for Microsoft Skype for Business
User's Manual 76 Document #: LTRT-11898
Note:
• When answering an incoming video call with a paired phone, the call is established. The
default device is the PC speaker/microphone rather than the phone. Subsequent audio
calls will be unaffected; the paired phone will still be the default device.
• In pairing mode, the user (Skype for Windows PC client /phone) can perform up to two
concurrent calls (incoming/outgoing). See the Release Notes.
7.11.6.2 Making Sure the IP Phone is Paired
You can determine from the IP phone's idle screen if the phone is paired with the Skype for
Windows client. The idle screen below indicates the phone is not paired:
The two interlocked rings in the idle screen below indicates the phone is paired.
After connecting, 'BToE Activated' pops up, and then disappears; the two interlocked rings
remain.
