Individual indications
RemedyIndication on display
Motor protection tripped
●
Cool down, wait.
●
If the fault indication display persists after cooling down:
-
Set selector switch to position Local control (LOCAL) and reset fault indication via push button
RESET.
-
Execute reset command via fieldbus.
●
Check fuses.
Thermal fault
Wrong oper. cmd (Collective signal 13)
Correct operation command, i.e. delete and set anew.
Incorr. cmd REMOTE1
Correct operation command, i.e. delete and set anew.
Incorr. cmd REMOTE2
Correct operation command.
Command fieldbus
Verify availability of function (parameter Activation M0212)Setpoint pos. disabled
Internal error (Collective signal 14)
Check motor protection monitoring.
IE mot. prot. monitor
Replace selector switch.
IE selector switch
Check power supply.
IE phase monitoring
Internal error:
The internal 24 V AC voltage supply of the controls has exceeded the power supply limits.
The 24 V AC voltage supply is used to control the reversing contactors, to assess the thermoswitches,
to supply the internal actuator heater and, as an option, to generate the 115 V AC supply for the customer.
●
Check power supply (level and wiring).
●
Check power supply unit.
IE 24 V AC
Check switchgear control.
IE output defective
Check actuator.
IE position transmitter
Check logic.
IE logic
Check fieldbus interface.
IE fieldbus
Check MWG.
IE MWG
Check local controls.
IE LC
Internal error: Calibration of Hall sensor 1 – 5 of the MWG is incorrect.
Check MWG.
IE Hall 1 calibration –
IE Hall 5 calibration
Check MWG.
IE MWG calibration
Check device configuration.
IE version
Check device configuration.
IE EEPROM
Check device configuration.
IE parameter
Check device configuration.
IE file access
Check device configuration.
IE reserve backup
Check device configuration.
IE registration
Check device configuration.
IE startup FB
Check device configuration.
IE startup sub-assy
Check device configuration.
IE LC exception
Check device configuration.
IE logic exception
Check device configuration.
IE MWG exception
Check device configuration.
IE bus exception
Check device configuration.
IE MWG end positions
Internal warning (Collective signal 15)
Check heater.
Wrn heater
