AUMA AC 01.2 - Page 149

DescriptionSignal
Approach position 16 counterclockwise
MPV: CCW Position 16
Clockwise actuator operation
MPV DriveCW
Counterclockwise actuator operation
MPV DriveCCW
Signal for controlling output contact
Input DIN 1
Signal for controlling output contact
Input DIN 2
Signal for controlling output contact
Input DIN 3
Signal for controlling output contact
Input DIN 4
Enables the selector switch function (LOCAL/OFF) on the local controls
Enable Local
Interlock: Enables operation command in direction OPEN
Enable OPEN
Interlock: Enables operation command in direction CLOSE
Enable CLOSE
Internal PID setpoint
PID internal setpoint 2
Activation of operation mode Remote II
Remote2_active
Operation command OPEN in operation mode Remote II
Remote2_OPEN
Operation command CLOSE in operation mode Remote II
Remote_2_CLOSE
Operation command STOP in operation mode Remote II
Remote2_STOP
PVST is executed
Execute PVST
Enable signal for <By-pass function>
Bypass Sync In
Enable signal for LPV function (synchronisation)
LPV Sync In
LPV slave actuator has reached end position CLOSED
LPV end position CL
Selector switch of LPV slave actuator is in position REMOTE
LPV sel.sw.Remote
LPV slave actuator is ready for operation
LPV system ok
Change-over of process controller setpoint source between fieldbus interface and I/O interface
PID setpoint I/O
Change-over of process controller actual value source between fieldbus interface and I/O interface
PID act. value I/O
Enable signal OPEN/CLOSE
RelOPENandCLOSE
