Device tab
The information on the Devices tab is typically defined in the WebCTRL® interface and then
downloaded to the controller. However, you would set the information on the controller setup Device
tab if the controller is stand-alone without a WebCTRL® system.
BACnet Object
Device Instance
Autogenerated—The Device Instance is automatically set to a number
equal to the (IP network number) x 100 + rotary switch address.
Assigned—Lets you enter a specific number that is unique on the BACnet
network.
Device Name
Autogenerated—The Device Name is automatically set as the word
device + the Device Instance. For example, device2423911.
Assigned—Lets you enter a specific name that is unique on the BACnet
network.
Device Location
You can enter an intuitive location for the device in the WebCTRL®
interface.
Device Description
You can enter an intuitive description for the device in the WebCTRL®
interface.
Configuration
APDU Timeout
How many milliseconds the device will wait before resending a message if
no response is received.
APDU Segment Timeout
How many milliseconds the device will wait before resending a message
segment if no response is received.
APDU Retries
The number of times the device will resend a message.
Controller Information
Clear Counts/Logs
Clears Reset counters and the three message history fields from the
Module Status.
Data Backup and Restore
Backup
Displays time of the last backup. Click button to backup the controller's
control programs, properties, and schedules.
Restore
Displays time of the last restore. Click button to restore the most recent
backup of the controller's control programs, properties, and schedules.
