Ports tab
IP Port
IP Addressing
Select the type of addressing the controller is to use. See Addressing the
G5CE (page 8).
Port S1
End of Network
Indicates status of the controller's End of Net? switch.
Active Protocol
Indicates status of the controller's Port S1 Configuration rotary switch.
0=Disabled
1=MS/TP
2=ARCNET
3=Modbus
Address
The address that is set on the three rotary switches. See To set the Port
S1 address and baud rate (page 12).
Port S2
End of Network
Indicates status of the controller's End of Net? switch.
Active Protocol
The protocol that has been enabled for Port S2 on the BACnet or Modbus
tab.
BACnet tab
The information on the BACnet tab is typically defined in SiteBuilder or the WebCTRL® interface and
then downloaded to the controller. However, you would set the information on the controller setup
BACnet tab if the router is stand-alone without a WebCTRL® system.
IP Port
BACnet Network Number
Disable Routing—Select if the IP port is not used.
Autogenerated—The BACnet/IP network number is automatically set to
2400.
Assigned—Lets you enter a specific number.
BACnet UDP Port
The port that the WebCTRL® application will use for BACnet
communication.
Enable NAT Routing
For future use.
Check if the G5CE is behind a NAT router (firewall).
Global NAT IP Address
For future use.
Public IP address of the NAT router.
Global NAT BACnet UDP
Port
For future use.
Port number assigned to the NAT router's public interface.
