Appendix - Module Status field descriptions
Field
Description
Date/Time
Date and time the Modstat was run
CM
The controller's rotary switch address (MAC address)
Model Name
Identifies the Product Type
Device Instance
A unique ID assigned to the controller
Driver built
When the driver was built
Downloaded by
When and where the last download was performed
Application Software Version
The name of the first control program that is downloaded
Data Partition Version
Not applicable to this device.
# PRGs initialized
# PRGs running
If applicable, the number of control programs that were downloaded
vs. the number that are running. If these numbers are not the same,
the controller has a problem such as lack of memory.
Driver version
The name, version, and date of the driver, as well as all the bundles
and versions.
Reset Counters:
The number of times each of the following events have occurred since
the last time the controller was commanded to clear the reset
counters.
See NOTE below this table.
Power failures
Interruption of incoming power
Commanded boots
Includes commands issued from the WebCTRL® interface such as the
zap manual command, plus commands issued during a memory
download.
System errors
Error in the controller's firmware or hardware
S/W Watchdog
timeouts
Watchdog is firmware that monitors the application firmware for
normal operation. If the watchdog firmware detects a problem, it
restarts the application firmware.
H/W Watchdog
timeouts
H/W Watchdog will restart the controller if it detects a severe problem
with the controller's operating system
System status
Gives the current status of the controller's operation. See LEDs (page
36) for all possible conditions.
Network status
Gives the current status of the controller's networks. See LEDs (page
36) for all possible conditions.
System error message
history
High-severity errors since the last memory download. Shows the most
recent 10 messages.
See NOTE below this table.
Warning message history
Low-severity errors and warning messages since the last memory
download. Shows the most recent 10 messages.
See NOTE below this table.
