Automated Logic OptiFlex G5CE User Manual

OptiFlex™ BACnet Integrator (part no. G5CE) Automated Logic Proprietary and Confidential A Carrier Company. © 2022 Carrier.
Rev. 6/9/2022 All rights reserved.
33
Port S2
End of Network
Indicates status of the controller's End of Net? switch.
Active Protocol
Shows one of the following:
• Modbus if enabled on the Modbus tab
• BACnet/MSTP if you enter a BACnet Network Number below for an
MS/TP network
• Disabled if neither of the above have been done
Address
The controller’s unique address on the MS/TP network.
MSTP Autobaud
Select Yes to enable this slave device to automatically receive its baud
rate from a master on the network that has the fixed baud rate.
MSTP Baud Rate
Set this to a baud rate that all other devices on the MS/TP network are
set to.
MSTP Max Master
To increase MS/TP performance, enter the highest address used on the
MS/TP network for a master controller. This number must be less than or
equal to 127.
MSTP Max Info Frames
This is the maximum number of information messages a controller may
transmit before it must pass the token to the next controller. Valid values
are 1 to 255.
TIP Set Max Info Frames to a number in the range 20 to 100 so that
the router does not become a bottleneck for traffic being routed from a
high-speed network to the slower MS/TP network.
BACnet Network Number
Select:
Disable Routing if Port S2 is not used.
Autogenerated to have the network number for Port S2 automatically set
to a number equal to ((IP network number + rotary switch address) x 10)
+ 3.
Assigned to enter a specific number.
Home Network
This is typically the network that is communicating with the building
automation system's application. This sets the BACnet Address of the
Device object.
Modbus tab
If the controller will be used with Modbus devices, see the Modbus Integration Guide for information on
using this tab.
Security tab
BACnet Firewall
If your BACnet Firewall configuration in the WebCTRL® interface did not
include the WebCTRL® server IP address, thus blocking communication
with the WebCTRL® server, you can disable the controller's BACnet
Firewall on the controller setup Security tab.
NOTE You can enable the BACnet Firewall only in the WebCTRL®
interface.
