Automated Logic OptiFlex G5CE User Manual

OptiFlex™ BACnet Integrator (part no. G5CE) Automated Logic Proprietary and Confidential A Carrier Company. © 2022 Carrier.
Rev. 6/9/2022 All rights reserved.
37
NET (Network Status) Tricolor LED
Color
Pattern
Condition
Message in Module
Status
Possible Solutions
Blue
On
One of the following issues:
• Port communication firmware
did not load properly
• Port communication firmware
is not running
• Invalid protocol selected
ARCNET/MSTP
firmware error
• Change rotary switch to
select valid protocol
• Cycle power
Blue
1 blink
Invalid address selected for
protocol
Invalid address
selection for
ARCNET/MSTP
Change rotary switch to
valid address
Blue
2 blink
Router has same MAC address as
another connected device
Duplicate address on
ARCNET/MSTP
Change rotary switch to
unique address
Blue
3 blink
Router is the only device on the
network
No other devices
detected on
ARCNET/MSTP
• Check that network
cable is connected
properly
• Check that baud rate is
correct
Blue
4 blink
Excessive errors detected over 3
second period
Excessive
communication errors
on ARCNET/MSTP
• Check that network
cable is connected
properly
• Check that baud rate is
correct
Blue
5 blink
ARCNET traffic overload possibly
due to circular router or excessive
COVs (change of values)
Event System Error -
FPGA RX FIFO full
• Check the network
configuration for a
circular route
• Increase the time
between COVs to
reduce excessive COV
traffic
Green
On
All enabled networks are
functioning properly
No errors
No action required
SYS (System Status) Tricolor LED
Color
Pattern
Condition
Message in Module
Status
Possible Solution
Red
1 blink
System is non-operational due to
excessive control program
abnormal exits
No control programs
started due to
frequent system
errors
Remove control programs
and download
