The display and display buttons
Issue 5 July 2001 13
The display and display buttons
The alphanumeric display provides information about callers, called parties, call
status, and call features. The console has a 1-line by 40-character display. The
console has 8 buttons in the display area that function as different modes for
viewing information. On the basic console, they are located on the display
module. On the enhanced console, they are located on the main console.
Figure 7. Display
These display mode buttons are as follows:
NOTE:
Your system manager may change the function of each button.
■ NORMAL MODE (comes with every console)
This button displays call-related information for active, incoming calls and
console-originated calls. For more information on information that displays
in normal mode, refer to Displaying call-related information later in this
chapter.
■ INSPECT MODE
This button displays call-related information for held calls when you are on
another call.
■ DATE TIME
This button displays the current time of day and date for five seconds.
■ TIMER (Elapsed Time)
This button displays elapsed time in hours, minutes, and seconds. Timing
begins when you press the T
IMER button and stops when you press the
button again.
40 character
display area
ph302and PDH 041597
