Understanding the console layout
4 DEFINITY ECS Console Operations
Physical layout of your console
At first glance, your console may look like an oversized phone with a few too
many buttons and lamps (lights). While your console can function like a phone, it
also manages several additional functions. In fact, your console, with its many
buttons and lamps, has functional groups designed to manage outside lines,
incoming calls, and special features.
Two types of consoles are described in this chapter: the 302A/B and the 302C/D
console. The following section contains drawings of 302A/B and 302C/D
consoles followed by information on the layout of buttons, indicators, and the call
display.
