57
Button Function Description
DATE & TIME
Displays the recording time of the data
selected on the time bar at the bottom of the
main user interface.
DISCONNECT
Disconnect network connection..
LIVE
Switches the search mode to live mode.
CAPTURE
Capture a still image from live screen.
MARK IN
Set the start time for video backup.
MARK OUT
Set the ending time for video backup.
BACKUP
Backup the selected recorded video as AVI
format.
SEARCH
CALENDAR
The calendar shows dates with recorded
video in a light blue and the selected date in
dark blue.
TIMELINE BAR
The timeline shows recorded data in dark
blue on the bar.
PLAYBACK
BUTTON
The playback buttons.
DISPLAY MODE
Select a channel and screen display mode.
Searching and playing video in the remote DVR
Video recorded in the remote DVR or Video recorded on the PC can be searched and played back.
1. Connect the network to the remote DVR and press SEARCH button. Then the mode is changed
from the live mode to the search mode.
Searching the video recorded in the remote DVR: Connect the network to the DVR..
Searching the video recorded in the PC: Do not connect the network to the DVR.
