Avidyne Entegra - Page 161

Appendix A – PFD A-3
A hollow magenta Heading, Altitude, or VSI bug indicates that the
bug is not coupled to or being used by the autopilot or flight
director.
The PFD will display altimeter, airspeed and vertical speed in
metric measurements:
Altimeter will display altitude in either Feet or Meters
Airspeed indicator will display airspeed in Knots and Kilometers
per Hour (KPH)
Vertical Speed Indicator will display in Feet per Minute (FPM) or
Meters per Minute (MPM)
Groundspeed will display in Knots or Kilometers per Hour
Bugs will be modified to correspond metric unit settings, except
the ASI bug (no autopilot integration will be allowed with the
Metric settings
The Bug Select tab enables you to set the following bugs:
Heading, Altitude, and Vertical Speed. It looks like the Nav
Display tab except that the right hand LSKs allow you to set
Autopilot Targets, Heading and Altitude.
Setting Heading
bug from the Bug
Select Tab
Press Set Heading LSK
Rotate the right-hand knob
As you rotate the knob, the bug
repositions and the new heading
value displays in the Hdg Sel
datablock.
Outer knob 10 degree
increments
Inner Knob 1 degree
increments
Setting Vertical
Speed bug from
the Bug Select tab
Press Set VS
Rotate the right-hand knob
As you rotate the knob, the bug
repositions and the new vertical
speed value displays on the
vertical speed tape.
Outer ring = 100ft
increments
Inner knob = 50ft
increments
Metric:
Outer ring = 30 mpm
increments
Inner knob = 15 mpm
increments
