Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
I 2 of 5 Set
Length 2
This feature specifies one of the barcode lengths for I 2 of 5 Length Control. Length 2 is the max-
imum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
The length includes the barcode’s check and data characters.
The length can be set from 2 to 50 characters. A setting of 0 specifies to ignore this length (only
one fixed length).
Table I 2 of 5 Length 2 Setting Examples provides examples for setting Length 2. See page 250
for detailed instructions on setting this feature.
I 2 of 5 Length 2
Setting
Examples
STEP ACTION EXAMPLES
1 Desired Setting
Ignore This
Length
4
Characters
14
Characters
50
Characters
2
Pad with leading
zeroes to yield two
digits
00 04 14 50
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT I 2 OF 5 LENGTH 2 SETTING
5
Scan Two Characters
From
Appendix D:
Keypad
‘0’ and ‘0’ ‘0’ and ‘4’ ‘1’ and ‘4’ ‘5’ AND ‘0’
6 Scan ENTER/EXIT PROGRAMMING MODE
Select I 2 of 5 Length 2 Setting
Make a mistake? Scan the CANCEL barcode
to abort and not save the entry string. You
can then start again at the beginning.
CANCEL
$CI2L2
~
DEFAULT
50 = Length 2 is 50 Characters
