Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
Standard 2 of 5
Set Length 2
This feature specifies one of the barcode lengths for Standard 2 of 5 Length Control. Length 2 is
the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length
Mode. Length includes the barcode’s check and data characters.
The length can be set from 1 to 50 characters. A setting of 0 specifies to ignore this length (only
one fixed length).
Table Standard 2 of 5 Length 2 Setting Examples provides examples for setting Length 2. See
page 250 for detailed instructions on setting this feature.
Standard 2 of 5
Length 2 Setting
Examples
Select Standard 2 of 5 Length 1 Setting
Make a mistake? Scan the CANCEL barcode
to abort and not save the entry string. You
can then start again at the beginning.
CANCEL
$CS2L1
~
DEFAULT
08 = Length 1 is 8 Characters
STEP ACTION EXAMPLES
1
Desired Setting (pad
with leading zeroes)
00 (Ignore
This Length)
07
Characters
15
Characters
50
Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT STANDARD 2 OF 5 LENGTH 2 SETTING
4
Scan Two Characters
From Appendix D:
Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
