References
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
Disable
Character
Specifies the value of the RS-232 host command used to disable the reader.
ASCII characters or any hex value from 0 to 0xFF can be selected.
To set the value:
1 Determine the desired character or value. A setting of 0xFF indicates the Disable Character is
not used (not available).
2 Use the ASCII Chart on the inside back cover of this manual to find the hex equivalent for the
desired character/value.
3 Go to page 43 and scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Pro-
gramming Mode.
4 Scan the barcode: SELECT DISABLE CHARACTER SETTING.
5 Scan the appropriate two alphanumeric characters from the keypad in Appendix D: Keypad,
that represent the desired character/value in step 1 above. The second character will cause a
two-beep indication.
6 Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming Mode.
This completes the procedure. See Table Disable Character Setting Examples for some examples
of how to set this feature.
Disable
Character
Setting
Examples
NOTE
Setting to previously defined characters such as XON, XOFF, or host com-
mands conflicts with normal operation of these characters. 8-bit data is not
recognized when the option Data Bits has been set as 7 Data Bits.
STEP ACTION EXAMPLES
1
Desired character/
value
‘d’ ‘}’ ‘D’
Disable Com-
mand
Not Used
2
Hex equivalent from
fig. 10 ASCII Chart
ASCII Chart
0x64 0x7D 0x44 0xFF
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT DISABLE CHARACTER VALUE SETTING
5
Scan Two Characters
From
Appendix D:
Keypad
‘6’ and ‘4’ ‘7’ and ‘D’ ‘4’ and ‘4’ ‘F’ AND ‘F’
6 Scan ENTER/EXIT PROGRAMMING MODE
